USB programble signal tower light ONN-M4-USB
USB programble signal tower light ONN-M4-USB
ONN-M4 USB programmble signal tower light that can communicate with the computer by connecting PC with the USB interface and the LED signal light controlled by the close-up program
Feature of USB programble signal tower light
- Use on signal ports above USB 1.1
Configuration requirements OS (32-bit/64-bit): Windows XP, Windows 7, Windows 10
Support programs: VC++, VB, Delphi(32-bit only), C#(64-bit only) - We provide the control source code, and the lighting control program can be developed according to different application software.
Once the serial port is created, connect to it over 9600 baud and send command codes to turn on and off the red, yellow and green LEDs and enable/disable the buzzer. There’s also a blink command, so you don’t have to continuously turn on/off the LED to have a pulsing/blinking effect.
As the updated version of M4-USB, M4T-USB has stronger functions,which integrated steady, flash, frequency and more colors options.
More details about M4T-USB signal tower, please check the link M4T-USB
Share This Product
Data
Tri-color signal tower light can communicate with the computer by connecting PC with the USB interface and the LED signal light controlled by the close-up program
- Use on signal ports above USB 1.1
Configuration requirements OS (32-bit/64-bit): Windows XP, Windows 7, Windows 10
Support programs: VC++, VB, Delphi(32-bit only), C#(64-bit only) - We provide the control source code, and the lighting control program can be developed according to different application software.
- Compatible with RS485
Structural Drawing
Order Info
| ① Mumber of Layers | |
| 1 | one layer |
| ② Mounting options | |
| A | Foldable |
| C | Pole plate |
| E | L shape bracket |
| ③ Voltage | |
| D | DC 5V |
| ④ Functions | |
| B | Steady |
| F | Steady with buzzer |
| S | Red flash |
| C | Red flash with buzzer |
| D | All flash |
| E | All flash with buzzer |
| ⑤Connect type | |
| T | PNP&NPN |
| C | Contact type |
| ⑥ LED color | |
| R | Red |
| Y | Yellow |
| G | Green |
| ⑦Diameter | |
| 60 | 60mm |
